3300µF 50V Radial Electrolytic Capacitor – High Performance, Long Life
Product Description:
This 3300µF 50V Aluminum Electrolytic Capacitor is engineered for high reliability and consistent performance in a wide range of electronic applications. With a surge voltage of 63V, high ripple current rating, and temperature tolerance from -40°C to +105°C, it’s ideal for power supplies, audio amplifiers, LED drivers, and industrial control circuits.
Its compact radial design and 7.5mm pitch make it easy to mount on standard PCBs, while the 2000-hour rated life at full load and high temperature ensures long-term durability even under demanding conditions.
Key Features:
- Capacitance: 3300µF
- Rated Voltage: 50V DC
- Surge Voltage: 63V DC
- Ripple Current: 2006mA (at 105°C, 100Hz)
- Tolerance: ±20%
- Operating Temperature Range: -40°C to +105°C
- Rated Lifetime: 2000 hours @ 105°C
- Mounting Type: Radial / Through-Hole
- Lead Pitch: 7.5mm
- Dimensions: 18mm (Diameter) x 35mm (Height)
Applications:
- Power supply smoothing and filtering
- Audio amplifier power stages
- LED lighting drivers
- Motor controllers
- Industrial and control electronics
- DIY electronics and repair projects
Package Includes:
- 5pcs x 3300µF 50V Radial Electrolytic Capacitor
Note:
- No retail packaging included.
- Please double-check voltage and physical size compatibility before installation.
